DC gear motor

  • XD5D200-RV30 200W RV geared DC motor

    XD5D200-RV30 200W RV geared DC motor

    200W DC motor+gearbox
    Model: 5D200GN-RV30
    Motor size: 90*250mm
    Power mode: DC
    Voltage: 24V
    Power: 200W
    Motor Type: Drive Motor
    GEARBOX SIZE – 30
    Output shaft speed: 110rpm
    Gearbox speed ratio: 20K
    Torque:14.6N.m/148.9kgf.cm

    inquirydetail
  • 4D60-12GN-21S DC reduction motor 1m wire ready for delivery

    4D60-12GN-21S DC reduction motor 1m wire ready for delivery

    Rotating speed selection:



    —600 rpm per minute
    —400 rpm per minute
    —300 rpm per minute
    —200 revolutions per minute
    —100 revolutions per minute
    —50 revolutions per minute
    —30 revolutions per minute
    —20 revolutions per minute
    —10 revolutions per minute
    —Other speeds





    Voltage :12V
    24V
    Product with brake or not :



    —with brake
    —Without brake
    inquirydetail
  • XD5D300-RV40 300W RV gear reduction DC motor

    XD5D300-RV40 300W RV gear reduction DC motor

    Voltage: 12VDC
    Power: 300W
    Motor size: 90*167mm
    Off-load speed: 2200rpm
    On-load Speed: 1850rpm
    Off-load current: 4A
    On-load current: 17.5A
    Motor out shaft size:12*35mm
    Turning direction: CW/CCW
    Gearbox TYPE – NMRV
    GEARBOX SIZE – 40
    GEARBOX OUTPUT BORE – 18 mm
    Output shaft speed: 55rpm
    Gearbox speed ratio: 40K
    Torque: 31.5N.m/400kgf.cm

    inquirydetail
  • XD5D60GN-RV30 60W RV gear reduction DC motor

    XD5D60GN-RV30 60W RV gear reduction DC motor

    Voltage: 12VDC
    Power: 60W
    Motor size: 130*90mm
    Motor speed: 1850-2200rpm
    Current: 4A
    Output shaft: single/double shaft
    Speed regulable
    Output shaft speed: 52.5rpm
    GEARBOX SIZE-30
    Gearbox speed ratio: 40K
    Rotate direction: ccw/cw

    inquirydetail
  • 5D90GN-RV40 12v24v DC worm gear motor

    5D90GN-RV40 12v24v DC worm gear motor

    Rated Power: 90W
    Rated voltage: 24V
    Off-load speed: 2100rpm
    On-load speed: 1800rpm
    Off-load curent: 0.6A
    On-load current: 5.5A
    On-load torque: 3.2 kg.cm
    Brush life: 3000h
    Speed ratio: 100K
    Output speed: 18rpm
    Output torque: 19.6N.M/200kg.cm

    inquirydetail
  • XD5D120-24A121SRV30 RV worm gear DC reduction motor

    XD5D120-24A121SRV30 RV worm gear DC reduction motor

    Voltage:24V
    Power: 120W
    Motor size: 90*167mm
    Motor Speed: 1800rpm/2100rpm
    Current: 13A
    Motor out shaft size:12*38mm
    Turning direction: CW/CCW
    Gearbox TYPE – NMRV
    GEARBOX SIZE – 30
    GEARBOX OUTPUT BORE – 14 mm
    GEAR RATIO – 15:1 -120rpm
    Single package size:43*26*21cm
    with reaction arm

    inquirydetail
  • 42GA775 DC reduction motor

    42GA775 DC reduction motor

    Sort by combination

    -42GA775 motor

    -Motor + bracket

    -Motor and bracket and speed regulator

    -Motor and speed regulator and bracket and power supply

    Rated voltage selection
    12v
    24v

    Output speed selection
    0 to 10 rpm
    0 to 30 rpm
    0 to 50 rpm
    0 to 100 rpm
    0 to 200 rpm
    0 to 300 rpm
    0 to 500 rpm
    Other speeds

    inquirydetail
  • 42GA775 DC reduction motor

    42GA775 DC reduction motor

    XD42GA775 DC reduction motor 12V24V gear high torque micro forward and reverse adjustable speed slow motor

    Sort by combination
    -Motor
    -Motor + bracket
    -Motor + bracket + speed control board + 0.75 square power cord
    Motor + bracket + speed control board + power supply + plug line + 0.75 square power line



    inquirydetail
  • 5D120-RV40 DC geared reduction motor

    5D120-RV40 DC geared reduction motor

    Industry-specific attributes

    Speed(RPM)
    2100RPM

    Continuous Current(A)
    13A

    Efficiency
    IE 1

    Other attributes

    Warranty
    1year

    Place of Origin
    China

    Brand Name
    XINDA

    Model Number
    5D120-RV40

    Usage
    BOAT, Car, Electric Bicycle, FAN, Home Appliance, Cosmetic instrument, SMART HOME

    Type
    GEAR MOTOR

    Torque
    various

    Construction
    Permanent Magnet

    Commutation
    Brush



    Product Name
    Linear Actuator

    Application
    Automatic Product

    Motor type
    RV gear reduction DC motor




    Place of Origin
    Mainland China




    Rated Voltage
    12V

    Power
    120W  (Can Customize)

    Size
    90*167mm




    Packaging and delivery

    Selling Units:
    Single item
    Single package size:
    L43*W26*21cm

    Single gross weight:
    2.5kg

    inquirydetail
  • 24v12v5v switching power supply DC 2a3a5a10a20A monitoring light strip transformer volt high power

    24v12v5v switching power supply DC 2a3a5a10a20A monitoring light strip transformer volt high power





    inquirydetail
  • XD5D200-24GU-22S 200W DC high power gear reduction motor 12V24V micro speed regulating motor forward and reverse slow speed motor

    XD5D200-24GU-22S 200W DC high power gear reduction motor 12V24V micro speed regulating motor forward and reverse slow speed motor

    Parameter information

    brand
    Xinda Motor
    model
    XD5D200-24GU-22S
    Origin
    Chinese mainland
    Voltage
    24V
    Power supply mode
    Direct current
    sort by type
    Motor without brake, Motor with brake
    power
    200W
    Voltage
    12V/24V
    Maximum current
    15A
    Output speed
    10 rpm – 1000 rpm
    Motor Type
    DC gear motor

    inquirydetail
  • 3D30GN12V24V DC 30W gear reduction motor

    3D30GN12V24V DC 30W gear reduction motor

    Voltage selection:
    12V
    24V
    Speed selection:
    600 revolutions per minute
    400 revolutions per minute
    300 revolutions per minute
    200 revolutions per minute
    100 revolutions per minute
    50 revolutions per minute
    30 revolutions per minute
    20 revolutions per minute
    10 revolutions per minute
    Other speeds

    inquirydetail
